ASRock Z890 Pro RS WiFi LGA 1851 ATX Motherboard DDR5 PCIe 5.0 Thunderbolt 4
The ASRock Z890 Pro RS WiFi ATX motherboard is built for Intel Core Ultra Series 2 processors on LGA 1851, delivering a balance of high performance and sensible pricing. It features a 16+1+1+1+1 power phase design with Dr. MOS, 1000uF capacitors, and a 2oz copper PCB, supporting DDR5 memory up to 9066+ MT/s (OC) with a maximum capacity of 256GB. It includes a PCIe 5.0 x16 slot, four M.2 slots, dual Thunderbolt 4 ports, Dragon 2.5G LAN, Wi-Fi 6E, and Nahimic audio.
Warranty, Exchange & Return Policy
Specifications
No specifications available
Details
The ASRock Z890 Pro RS WiFi ATX motherboard is the balanced choice for building a professional system based on Intel Core Ultra Series 2 processors on LGA 1851. Part of the Race Sport (RS) Edition lineup, an evolution of the popular PRO series, it features a modern, futuristic design combining linear and angular elements. It runs on the Intel Z890 chipset with Turbo Boost Max 3.0, Thermal Velocity Boost, Adaptive Boost, and an integrated NPU for AI acceleration, and supports BIOS updates to enable Intel 200S Boost for improved performance.
Key Highlights:
- LGA 1851 Socket with Intel Z890 Chipset: Supports Intel Core Ultra Series 2 processors with Intel 200S Boost support via BIOS update for improved performance.
- 16+1+1+1+1 Power Phase with Dr. MOS: Delivers stable, clean power to the CPU even under overclocking loads, with 1000uF durable capacitors and a 2oz copper PCB for better heat dissipation.
- DDR5 Memory up to 9066+ MT/s (OC): Four DIMM slots with 256GB maximum capacity, supporting Intel XMP 3.0x and the exclusive Memory OC Shield to reduce electromagnetic interference and enhance high-frequency stability.
- PCIe 5.0 x16 Slot: Offering up to 128GB/s bandwidth, with support for x8/x8 or x8/x4/x4 splitting to distribute bandwidth across graphics cards and other devices.
- Four M.2 Slots: One Blazing M.2 (PCIe Gen5 x4) at up to 128Gb/s and three Hyper M.2 (PCIe Gen4 x4), with enlarged heatsinks and a bottom heatsink for SSD cooling.
- Dual Thunderbolt 4 Ports: Up to 40Gb/s transfer speed per port, supporting 8K@60Hz or 5K@120Hz displays, USB PD 3.0 charging at 15W, and daisy-chaining of peripherals.
- Dragon 2.5G LAN and Wi-Fi 6E: With ASRock WiFi 2.4/5/6GHz antenna, delivering 2.5Gbps wired networking and 6GHz wireless connectivity with Bluetooth 5.3 support.
- Realtek ALC897 7.1 Audio with Nahimic: Delivers high-definition immersive audio with Sound Tracker, Static Noise Suppression, and Echo Cancellation for enhanced gaming and chat experiences.
- EZ DIY Design and Intelligent Cooling: BIOS Flashback button, Post Status Checker for diagnostics, PWM/DC fan support with multiple thermal sensors, a front USB-C header at 20Gb/s, and a coordinated black design to match other components.
