Intel Core i9-12900KF 16-Core 24-Thread LGA 1700 Processor Tray
The Intel Core i9-12900KF Tray variant delivers a hybrid architecture with 16 cores (8 Performance + 8 Efficient) and 24 threads, reaching 5.20 GHz max turbo with 30MB Smart Cache. Built on Intel 7 at 125W base power rising to 241W. Supports DDR5 4800, DDR4 3200, and PCIe 5.0. No integrated graphics, no cooler included, and warranty terms differ from the boxed version. Confirm terms with your local seller.
Warranty, Exchange & Return Policy
Specifications
Details
The Intel Core i9-12900KF Tray variant is the exact same processor with identical functionality to the boxed version [citation:4]. The only differences are packaging and warranty. It ships without a retail box and without a cooler, typically sold to system integrators and resellers [citation:4]. It runs a hybrid architecture with 16 cores and 24 threads on the LGA 1700 socket.
Key Highlights:
- Identical Performance to Boxed: There are no functional differences between Tray and Boxed processors carrying the same processor number [citation:4].
- 16-Core Hybrid Architecture: 8 Performance-cores and 8 Efficient-cores with 24 threads via Hyper-Threading, intelligently balancing speed and power draw.
- 5.20 GHz Max Turbo: Intel Turbo Boost Max Technology 3.0 automatically raises the fastest core's frequency for single-threaded tasks.
- 30MB Intel Smart Cache: Paired with 14MB of L2 cache to reduce latency when accessing frequently reused data.
- DDR5 and DDR4 Support: Up to DDR5 4800 MT/s or DDR4 3200 MT/s across two channels, with a max bandwidth of 76.8 GB/s.
- PCIe 5.0 and PCIe 4.0: Up to 20 PCIe lanes in 1x16+4 or 2x8+4 configurations, driving modern graphics cards and NVMe drives.
- 125W Base Power: Processor Base Power reaches 241W at maximum turbo, requiring a capable cooler and motherboard.
- No Integrated Graphics: The KF suffix denotes no iGPU, so a discrete graphics card is required.
- No Cooler Included: The Tray variant does not ship with a heatsink or fan, so an LGA 1700-compatible cooler must be purchased separately [citation:4].
- Warranty Through Seller: Intel does not provide direct warranty support for Tray processors to end users. Warranty is provided by the place of purchase or local distributor [citation:6].
