Wi-Tek 5GHz 300Mbps 16dBi Outdoor Wireless Bridge Kit
The Wi-Tek WI-CPE515H-KIT is a professional 5GHz 300Mbps outdoor wireless bridge kit featuring a 16dBi directional antenna for long-range point-to-point data transmission. Designed for durability and stability, it is an ideal solution for remote IP surveillance and outdoor network connectivity.
Warranty, Exchange & Return Policy
Specifications
Details
The Wi-Tek WI-CPE515H-KIT provides a cost-effective, long-range wireless network solution tailored for video surveillance and data transmission in challenging outdoor environments. Utilizing the 5GHz frequency band, this kit delivers stable wireless speeds of up to 300Mbps, ensuring reliable performance for high-definition video streaming. It supports both Point-to-Point (PtP) and Point-to-Multipoint (PtMP) networking modes, offering the flexibility needed for various outdoor deployments. Featuring a built-in 16dBi 2x2 dual-polarized directional MIMO antenna, the system can achieve transmission distances of up to 8km under ideal conditions. The enclosure is built to IP65 standards, guaranteeing resilience against harsh weather conditions and ensuring all-weather stability. Installation is simplified through 24V Passive PoE support, which allows for simultaneous data and power transmission over a single Ethernet cable. Management is streamlined with the Wi-Tek Cloud platform, enabling visual management and real-time monitoring for increased operational efficiency. This system is the preferred choice for industrial wireless solutions, rural internet access, and urban network expansion.
Specifications
- Wireless Standard: IEEE 802.11a/n
- Frequency Band: 5.150 - 5.850 GHz
- Wireless Speed: Up to 300Mbps
- Antenna Gain: 16dBi (Directional)
- Interface: 2 x 10/100Mbps RJ45 Ports
- Max Transmission Range: Up to 8km
- Power Supply: 24V Passive PoE Input
- Ingress Protection: IP65 Rated
