Wi-Tek WI-PS205(V4) 4-Port PoE Switch with 60W Hi-PoE and Extend Mode
The Wi-Tek WI-PS205(V4) is a reliable 4-port PoE switch featuring 60W Hi-PoE support and a dedicated Extend Mode for long-distance surveillance connectivity.
Warranty, Exchange & Return Policy
Specifications
Details
The Wi-Tek WI-PS205(V4) is an unmanaged PoE switch designed specifically for surveillance applications and small network deployments. It offers 4 ports that support PoE, with Port 1 specifically engineered to handle Hi-PoE power up to 60W for high-demand devices like PTZ cameras. The remaining three PoE ports support standard IEEE 802.3af/at with up to 30W of power per port, ensuring flexible connectivity for various IP devices. A key feature of this model is the integrated Smart DIP switch, which allows users to easily enable Extend Mode, pushing data and power transmission distances up to 250 meters. The device also includes built-in PoE Watchdog functionality, which automatically detects and reboots unresponsive connected devices to maintain network uptime. With its plug-and-play design, no configuration is required, making installation quick and efficient for technicians. The unit provides a total PoE power budget of up to 60W, encased in a durable, fanless housing that ensures silent and reliable operation. This switch is the ideal cost-effective solution for expanding network infrastructure in home, office, or security environments.
Specifications
- Ports: 4 x 10/100Mbps PoE RJ45, 2 x 10/100Mbps Uplink RJ45
- PoE Standard: IEEE 802.3af/at, Hi-PoE (Port 1)
- Power Budget: 60W Total
- Extend Mode: Up to 250m Transmission
- Smart Features: PoE Watchdog, Port VLAN, CCTV Mode
- Design: Fanless, Plug-and-Play
- Dimensions: 140mm x 76.7mm x 27.7mm
- Operating Temperature: -10°C to 50°C
