XFX Mercury AMD Radeon RX 9070 XT OC Gaming Edition 16GB Graphics Card
Black
WhiteThe XFX Mercury AMD Radeon RX 9070 XT OC delivers exceptional 1440p and 4K gaming performance on AMD RDNA 4 architecture, manufactured on a 4nm process with 4096 Stream Processors and 64 Compute Units. It carries 16GB of GDDR6 memory at 20Gbps on a 256-bit bus, delivering 640GB/s of total bandwidth. Boost clock reaches 2970MHz, with a triple-fan cooling system, a nickel-plated cold plate, and PTM7950 thermal compound. A classic black design with a white LED bar and a PCIe 5.0 interface, requiring an 800W power supply and dual 8-pin connectors.
Warranty, Exchange & Return Policy
Specifications
Details
XFX built the Mercury AMD Radeon RX 9070 XT OC Gaming Edition for anyone who wants exceptional 1440p and 4K gaming performance in a classic black design. It runs on AMD RDNA 4 architecture manufactured on a 4nm process, with 64 Compute Units and 4096 Stream Processors, plus 64 Ray Accelerators and 128 AI Accelerators for improved lighting and shadow realism. Clocks reach 1660MHz base, 2400MHz game, and up to 2970MHz boost.
Key Highlights:
- AMD RDNA 4 Architecture: A modern 4nm process with 64 Compute Units and 4096 Stream Processors, delivering improved gaming and ray-tracing performance at 1440p and 4K.
- 16GB GDDR6 Memory: Memory at 20Gbps on a 256-bit bus, delivering 640GB/s of total bandwidth for modern games at maximum settings.
- Boost Clock Up to 2970MHz: A 2400MHz game clock and 1660MHz base clock, for stable performance in games and heavy applications.
- Triple-Fan Mercury Cooling: A Mercury cooling solution with three double ball-bearing fans, a nickel-plated cold plate, and 6mm heatpipes for efficient heat dissipation.
- PTM7950 Thermal Compound: A phase-change thermal compound improving heat transfer and holding thermal performance steady over the long term.
- White LED Bar: A white LED bar on the shroud, adding a subtle visual touch to your build without full RGB lighting.
- PCIe 5.0 Interface: Supports PCI Express 5.0 x16 for compatibility with modern motherboards and faster data transfer.
- Multiple Display Outputs: Three DisplayPort 2.1a and one HDMI 2.1b, supporting up to 8K resolution with VRR, FRL, and DSC, and up to four displays.
- AMD Software Technologies: Supports AMD FidelityFX Super Resolution 4, Radeon Super Resolution, HYPR-RX, and FreeSync, reducing latency and improving game responsiveness.
- Power Requirements: 304W TGP (reference) with two 8-pin power connectors, and a recommended 800W power supply minimum.
